    Top Speed Laminate Machine Wenzhou Machinery

    Ask Lasest Price
    Brand Name : AMAN
    Certification : CE,ISO9001
    Model Number : BJ-Y1050
    Price : $100000
    Delivery Time : with in 45 days after got your payment
    Payment Terms : T/T L/C
    Supply Ability : 100 sets/years
    • Product Details
    • Company Profile

    Top Speed Laminate Machine Wenzhou Machinery


    PET PVC BOPP Self Adhesive Coating Machine / peanut coating machine


    The feature and application:
    this machine can be used for Laminating Steel, Coating Steel . and it is a better replacement of traditional direct-printing on the tinplate. which is heating the multicolor printed plastic film, and then paste it on the thin cold rolled steel plate.
    it is the latest technology. during whole process, it is all by fully automatically. printing and lamination is in the same time.
    laminated film material can be PET, PP. etc..laminated metal material can be tin.



    ATTENTION!

    The Technical Parameter serves as a guide only.

    Any question, inquiry me!

    laminating material
    MaterialThickness
    cellophane20-30 um
    CPP20-60um
    PET12-60um
    NY12-50um
    OPP/BOPP20-60um
    PE30-100um
    tin0.15-0.4mm
    foil8-40um
    laminated film15-60mm

    Specification list
    ItemDetail
    lamination width600-1050mm
    machine speed60m/min
    lamination speed50m/min
    first unwinding dia600mm
    second unwinding dia600mm
    winding dia600mm
    winding coreinflatable shaft
    rubber coating callender dia.165mm
    rubber coating capacity350kg
    solidity20-30%
    tension set up3-30kg
    film heater length9000mm*1 set
    metal sheet heater length6500mm*1 set
    film heater temperature100
    metal sheet heater temperature200
    drying methodelectrical heating
    laminating pressure2100kg
    laminating temperature100
    total power100kw
    outer size30000*2900*4500mm
    machine total weight30000kg

    Main Component:
    hydraulic unwinding unit
    welding S callender unit
    film unwinding unit
    coating unit
    film heating tunnel unit
    metal sheet heating tunnel unit
    laminating unit
    film winding unit
    rewinding S callender unit
    hydraulic winding machine


    Samples:


    We can making for your machine, such as soft loop handle bag /plastic dog food bag /wicketer bag /patch bag/plastic coffee pouch
